Wholesale Valves by Air by HuiYi Valve

Product details of the wholesale valves

Product Overview

HuiYi Valve wholesale valves is manufactured using top-notch materials in conformity with the industry quality standards. The product has been tested for performance and durability. The wholesale valves produced by our company can be applied to different fields and scenarios. So the different requirements of different people can be satisfied. The continuously quality service shows Wenzhou Huiyi Valve Technology Co.,Ltd's ability.

Product Introduction

To better learn about wholesale valves, HuiYi Valve will provide detailed pictures and detailed information in the following section for your reference.

Product details

Product Overview

● High-quality materials: Made of corrosion-resistant 304 and 316 stainless steel, as well as A105 carbon steel, to ensure long-term durability and reliability.

● High-pressure capability: Withstands pressures up to 3000 to 6000 Psi, suitable for extreme working conditions.

Butt-welded design: Provides a sturdy butt-welded connection to ensure leak-free operation.

● Wide application: Suitable for industries such as oil, gas, and chemicals, and suitable for a variety of fluid media.

● Strict standards: Follow international standards such as API and ASME to ensure product quality and performance.

● High temperature resistance: Adapts to a wide temperature range to meet the needs of different environments.

● Flexible connection: Provides a variety of connection methods, including flanges, threads, etc., to adapt to different piping systems.

Advantages and features

● Corrosion resistance: Stainless steel material effectively resists corrosion and extends service life.

● Easy operation: Simple design, easy installation and maintenance.

● Safe and reliable: Meets industry safety standards to ensure safe operation.

● Customized service: Customized solutions can be provided according to customer needs.

Dimension

Connection		Ordering number	Orifice (mm)	Cv	Size(mm)
Inlet/outlet	Size				A	B	C	D	E
Metric tube	6mm	HY-HP2BVFT-6M	10	1.2	45.5	90.4	44	130	32
	8mm	HY-HP2BVFT-8M		2.7	46.1	92.2	44	130	32
	10mm	HY-HP2BVFT-10M		4.8	47.1	94.2	44	130	32
	12mm	HY-HP2BVFT-12M		7.5	49.5	99	44	130	32
	14mm	HY-HP2BVFT-14M		7.5	49.5	99	44	130	32
	16mm	HY-HP2BVFT-16M	14	10	54	108	48	145	41
	18mm	HY-HP2BVFT-18M		10	54.1	108.2	48	145	41
	20mm	HY-HP2BVFT-20M	19	19	59.5	119	53	160	50
	22mm	HY-HP2BVFT-22M		19	59.5	119	53	160	50
	25mm	HY-HP2BVFT-25M		30	64	128	53	160	50
Inch tube	1/4”	HY-HP2BVFT-1/4	10	1.2	45.3	90.6	44	130	32
	3/8”	HY-HP2BVFT-3/8	10	3.7	46.8	93.6	44	130	32
	1/2”	HY-HP2BVFT-1/2	10	7.5	49.4	98.8	44	130	32
	5/8”	HY-HP2BVFT-5/8	14	10	53.8	107.6	48	145	41
	3/4”	HY-HP2BVFT-3/4	14	10	53.8	107.6	48	145	41
	3/4”	HY-HP2BVFT-3/4	19	19	59.4	118.8	53	160	50
	1”	HY-HP2BVFT-1	19	30	63.9	127.8	53	160	50
Female NPT	1/4”	HY-HP2BV-1/4	10	7.5	36	72	44	130	32
	3/8"	HY-HP2BV-3/8	10	7.5	36.7	73.4	44	130	32
	1/2”	HY-HP2BV-1/2	10	7.5	41.5	83	44	130	32
	1/2”	HY-HP2BV1-1/2	14	10	47.5	95	48	145	41
	3/4"	HY-HP2BV-3/4	14	10	47.5	95	48	145	41
	3/4"	HY-HP2BV1-3/4	19	30	48.1	96.2	53	160	50
	1”	HY-HP2BV-1	19	30	52.9	105.8	53	160	50
Male NPT	1/4"	HY-MHP2BV-1/4	10	3.7	41.7	83.4	44	130	32
	3/8"	HY-MHP2BV-3/8	10	7.2	41.7	83.4	44	130	32
	1/2”	HY-MHP2BV-1/2	10	7.5	46.5	93	44	130	32
	1/2”	HY-MHP2BV1-1/2	14	10	51	102	48	145	41
	3/4"	HY-MHP2BV-3/4	14	10	51	102	48	145	41
	3/4"	HY-MHP2BV1-3/4	19	19	56.5	113	53	160	50
	1”	HY-MHP2BV-1	19	30	61.4	122.8	53	160	50

Main Parts

No.	Part Name	Material
1	Handle	Plastic
2	Stem Nut	316/304
3	Stem	304
4	Body	316/304
5	Ball	316/304
6	Ball Seat	PTFE
7	Stem Packing	PTFE



FAQ

1

How many is the MOQ ?

10 pcs

2

How long is the delivery time ?

It depends on the quantity Small quantity order , 7-15 days Mass quantity order , 20-30 days

3

What is the payment term ?

30% T/T before production, the balance before shipment 50% T/T before production , the balance is paid after customers see the copy of sea B/L 100% L/C at sight For other payment terms , we can discuss

4

What payment method you have ?

We can accept payment via paypal , western union , T/T , L/C

5

How long is the guarantee period ?

The guarantee period is 12 months after the goods arrive in customers’ company , or 18 months after the goods are shipped from our company

6

If there is quality problem , then how can you solve it ?

During the guarantee period , if there are quality problems , please contact us , we will take positive action , the solution is that , if we can repair , then we repair , if we can not repair , then we will send new items to customers to replace unqualified items , customers do not need to send us the unqualified items .

7

Do you have OEM/ODM service ?

Yes, we have OEM/ODM service , we can put your logo on our products by laser marking .

8

How can we know your product quality ?

At first , we can send you free samples , you check our quality , then you can place small order to check the quality again , if the quality is ok , then you place bulk order .

9

For the customized products , how can you make sure the quality ?

We will make samples as per your drawing or sample first , after get your approval , then we start to arrange mass production .

10

What is the shipping method ?

Small quantity products usually are shipped by international express or air logistic , if large quantity , we will ship them by sea .

Company Information

Wenzhou Huiyi Valve Technology Co.,Ltd is a modern company in With the main focus on the business range includes scientific research, production, marketing and service. Since the inception, HuiYi Valve has always complied with the development strategy of 'talent-based, market-oriented, technology-supported, and efficiency-aimed'. We are committed to becoming a leader in the domestic market. HuiYi Valve has a group of senior engineers to form a technical team. Moreover, we have many experienced production personnel. All this builds a stable foundation for vigorous development. HuiYi Valve has professional engineers and technicians, so we are able to provide one-stop and comprehensive solutions for customers.
Our products are guaranteed to be quality. Customers with needs are welcomed to contact us for purchase.
