Product Description
High Pressure Tolerance:Its pressure resistance can reach 25Mpa-40Mpa.Strong resistance to high pressure makes it suitable for various media such as tube,gases, fluid, etc.
Reliable Fastening:The stainless compression fitting adopts threaded connection, which is reliable and not easy to loosen, effectively preventing water or gas leakage in the tube and ensuring the safe operation of the pipeline system.
304 316 stainless steel:High-quality stainless steel construction for durability and corrosion resistance.
Double Sleeve Ferrules:better sealing performance,more effectively prevent leakage
more stable:it easier to connect and disconnect fitting, reducing the risk of damage and failure during operation.
Dimension
|
MODEL NUMBER |
TUBE OD |
DIMENSIONS(INCH) |
|||
| T,INCH | A | D | E |
F |
|
| HY-UE-1/16 | 1/16 | 0.70 | 0.34 |
0.05 |
3/8 |
| HY-UE-1/8 | 1/8 | 0.88 | 0.50 |
0.09 |
3/8 |
| HY-UE-3/16 | 1/8 | 1.00 | 0.54 |
0.12 |
1/2 |
| HY-UE-1/4 | 1/4 | 1.06 | 0.60 |
0.19 |
1/2 |
| HY-UE-5/16 | 5/16 | 1.13 | 0.64 |
0.25 |
9/16 |
| HY-UE-3/8 | 3/8 | 1.20 | 0.66 |
0.28 |
5/8 |
| HY-UE-1/2 | 1/2 | 1.42 | 0.90 |
0.41 |
13/16 |
| HY-UE-5/8 | 5/8 | 1.50 | 0.96 |
0.50 |
15/16 |
| HY-UE-3/4 | 3/4 | 1.57 | 0.96 |
0.62 |
1-1/16 |
| HY-UE-7/8 | 7/8 | 1.76 | 1.02 | 0.72 |
1-3/8 |
| HY-UE-1 | 1 | 1.93 | 1.23 | 0.72 |
1-3/8 |
Product details
Company Advantages
· HuiYi Valve wholesale pipe fittings is made of durable and high quality material but with reasonable price.
· Its production strictly follows the ISO 9001 international quality certification system.
· HuiYi Valve has won the recognition and trust of more clients for the high quality of wholesale pipe fittings.
Company Features
· Fully engaged in the R&D and production of wholesale pipe fittings, Wenzhou Huiyi Valve Technology Co.,Ltd has become widely recognized.
· We have established a professional team. They are equipped with expertise in the wholesale pipe fittings industry, offering creative process optimizations between us and our customers.
· We are continuously analyzing ways to reduce the energy we use in our processes. Today our average usage in all mills is within or below the levels prescribed by both domestic and international standards. Ask!
Application of the Product
wholesale pipe fittings is one of the main products of HuiYi Valve. With wide application, our product can be applied to different industries and fields. And it is deeply loved and favored by customers.
We will communicate with our customers to understand their situations and provide them with effective solutions.
