Product details of the valves and fittings
Quick Detail
The appearance of HuiYi Valve valves and fittings looks very attractive. In terms of the quality, it is totally enhanced by our QC team by following the quality system. HuiYi Valve's valves and fittings is widely used in the industry. Wenzhou Huiyi Valve Technology Co.,Ltd can ensure quality of our valves and fittings.
Product Description
HuiYi Valve will show you product's specific details below.
Product Description
Female threads for connecting to male threaded pipe fittings
SUS body and ball for extra strength and corrosion resistance
Inline valve for connecting two pipes going in the same direction with Double-seal system
Heavy duty stainless handles to increase service life, fast 1/4 turn open or closed operation
Standard port flow for smaller valve size, each valve individually tested for maximum safety about Water, Oil, and Gas(no freezing)
Dimension
Size |
1/4” |
3/8” |
1/2” |
3/4” |
1” |
D |
7 |
7 |
9.2 |
12.5 |
15 |
L |
42 |
42 |
46 |
54 |
65 |
H |
26.5 |
26.5 |
26.5 |
31.5 |
64 |
W |
22.5 |
22.5 |
22.5 |
22.5 |
22.5 |
Main Parts
No. |
Part Name |
Material |
1 |
Handle |
316/304 |
2 |
Stem Nut |
316/304 |
3 |
Stem |
304 |
4 |
Body |
316/304 |
5 |
Ball |
316/304 |
6 |
Ball Seat |
PTFE |
7 |
Stem Packing |
PTFE |
