Needle Valve Manufacturer Normal Temperature - - HuiYi Valve

Working Temperature:
Normal temperature, high temperature
Packing:
Inner case is carton, outside package is plywood case
Transaction mode:
By sea, By air, By truck , By international express
Medium:
Oil, Gas, Water
Needle:
F304 F316 F304L F316L
Inquiry

Product Description

Needle valves control fluid movement accurately, hence the name flow control valve.

When the handle is turned on and the stem is being rotated, the needle rises up from the seat and fluid flows through. This allows maximum accuracy as the tiniest change of the needle will affect the fluid movement.

The design of the seat and needle helps to avoid any gap for the fluid movement when the needle is put into place.

Dimension

Item

DN

Td

H

L

L1

N

HY-MFNV(1)-1/4

DN6

G1/4

75

58

75

60

HY-MFNV(1)-3/8

DN10

G3/8

75

58

78

60

HY-MFNV(1)-1/2

DN15

G1/2

80

62

66

60

HY-MFNV(1)-1/2

DN20

G3/4

80

57

70

60

Main Parts

No.

Part Name

Material

1

Handle

316/304

2

Stem Nut

316/304

3

Stem

304

4

Body

316/304

5

Needle

316/304

6

Stem Packing

PTFE

Product details

图片1 (26)
图片1 (26)
图片2 (24)
图片2 (24)
图片3 (17)
图片3 (17)

Main Parts

No.

Part Name

Material

1

Handle

316/304

2

Stem Nut

316/304

3

Stem

304

4

Body

316/304

5

Needle

316/304

6

Stem Packing

PTFE


Company Advantages

· Meticulous design and production process make HuiYi Valve needle valve manufacturer fine in the workmanship.

· needle valve manufacturer enjoys good reputation and trust in the users.

· The product is popular in the domestic and overseas market with huge economic benefits.


Company Features

· Wenzhou Huiyi Valve Technology Co.,Ltd has carved a niche as one of the leading needle valve manufacturer Manufacturers in China.

· Our company has attracted international attention for our high-quality needle valve manufacturer.

· Wenzhou Huiyi Valve Technology Co.,Ltd has been endeavoring to ensure the quality of the service. Ask online!


Application of the Product

needle valve manufacturer of HuiYi Valve can be used in various scenarios in different fields.

HuiYi Valve insists on providing customers with comprehensive solutions based on their actual needs, so as to help them achieve long-term success.

Contact us
we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
