Globe Valve Manufacturer Normal Temperature by HuiYi Valve
Product Features
Made of high quality stainless steel material, this globe valve is sturdy and durable.
The internal fluid of valve body is straight through which allows fluid to in a straight line and the resistance is small.
It's easier to open and close, because the movement direction of the disc is perpendicular to the direction, whether on or off.
It is suitable for water, oil, gas, etc.
Widely used in mechanical equipment, chemical equipment, industrial equipment, water supply and drainage equipment, pharmaceutical equipment, petrochemical equipment, etc.
Dimension
|
Size |
∅ D(mm) |
L(mm) |
H(mm) |
∅ D1(mm) |
|
1/2” |
15 |
66 |
100 |
70 |
|
3/4” |
20 |
80 |
106 |
70 |
|
1” |
25 |
90 |
118 |
80 |
|
1-1/4” |
32 |
105 |
134 |
80 |
|
1-1/2” |
40 |
120 |
152 |
100 |
|
2” |
50 |
141 |
172 |
100 |
Main Parts
|
No. |
Part Name |
Material |
|
1 |
Body |
CF8/CF8M |
|
2 |
Petal |
CF8/CF8M |
|
3 |
Stem |
316 |
|
4 |
Gasket |
PTFE |
|
5 |
Cap |
CF8/CF8M |
|
6 |
Washer |
316/304 |
|
7 |
Nut |
304 |
|
8 |
Ring |
304 |
|
9 |
Hand Wheel |
Aluminum |
|
10 |
Gland Ring |
CF8/CF8M |
|
11 |
Stem Packing |
PTFE |
Product details
Main Parts
|
No. |
Part Name |
Material |
|
1 |
Body |
CF8/CF8M |
|
2 |
Petal |
CF8/CF8M |
|
3 |
Stem |
316 |
|
4 |
Gasket |
PTFE |
|
5 |
Cap |
CF8/CF8M |
|
6 |
Washer |
316/304 |
|
7 |
Nut |
304 |
|
8 |
Ring |
304 |
|
9 |
Hand Wheel |
Aluminum |
|
10 |
Gland Ring |
CF8/CF8M |
|
11 |
Stem Packing |
PTFE |
Company Advantages
· Wenzhou Huiyi Valve Technology Co.,Ltd put lots of time and energy even on outline of globe valve manufacturer.
· This product defines the meaning of remarkable quality and long-lasting stability.
· The product has been widely recognized by customers and adopted by more and more people.
Company Features
· HuiYi Valve is a vanguard brand in globe valve manufacturer industry of China.
· The workshop has been repleted with all kinds of advanced manufacturing machines. These machines feature high performance in machining accuracy and have a high automation level. This contributes to improving the overall productivity.
· Wenzhou Huiyi Valve Technology Co.,Ltd faithfully hopes to establish partnerships with customers around the world. Inquire now!
Application of the Product
The globe valve manufacturer produced by our company is widely used in various industries and fields.
HuiYi Valve provides customers with unique solutions to meet their individual needs.
