3 Piece Ball Valve Normal Temperature by HuiYi Valve

Working Pressure:
1000 WOG
Working Temperature:
Normal temperature
Model:
Q11F-2PC
Ball:
F304 F316 F304L F316L
Structure:
Full Bore
Inquiry

Product details of the 3 piece ball valve


Product Overview

HuiYi Valve 3 piece ball valve is made from high-quality materials in a sophisticated manufacturing facility. A strict quality check on different quality parameters has been carried out throughout the whole production to ensure the product is completely defect-free and has good performance. The 3 piece ball valve produced by HuiYi Valve can be used in many fields. We strive to be different from others by developing high quality 3 piece ball valve through comparison with many overseas products.


Product Description

HuiYi Valve's 3 piece ball valve is of excellent quality, which is reflected in the details.

Dimension

Size

∅ d(mm)

L(mm)

H(mm)

W(mm)

1/4”

9.2

54

54

110

3/8”

12.8

54

55

110

1/2”

15

57

58

115

3/4”

20

68

61

115

1”

25

80

77

128

1-1/4”

32

91

81

128

1-1/2”

38

103

90

155

2”

50

124

108

155

2-1/2”

65

160

132

230

3”

80

185

145

230

4”

100

224.5

185

335

Product details

图片3 (2)
图片3 (2)
图片2 (2)
图片2 (2)
图片1 (2)
图片1 (2)

Main Parts

NO.

Part Name

Material

1

Handle Cover

Plastic

2

Body

CF8/CF8M

3

Ball Seat

PTFE

4

Ball

CF8/CF8M

5

Cap

CF8/CF8M

6

Joint Gasket

PTFE

7

Thrust Washer

PTFE

8

Stem Packing

PTFE

9

Gland Nut

304

10

Stem Washer

304

11

Stem

316/304

12

Stem Nut

304

13

Locking Device

304

14

Handle

304


Company Introduction

Wenzhou Huiyi Valve Technology Co.,Ltd is a modern company integrating R&D, sales and production. We are chiefly engaged in the production of HuiYi Valve has built a service system that meets the needs of consumers. It has won wide acclaim and support from customers. We are waiting for consulting from new and old customers!

Contact us
we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
